Cooler Master HAF 500 Mid-Tower PC Case with 2x 200mm ARGB fans, rotatable 120mm GPU fan, supports up to E-ATX motherboards, dual 360mm radiators, tempered glass side panel, and USB 3.2 Gen 2 Type-C | 6199 EGP

Cooler Master HAF 500 Mid-Tower PC Case with 2x 200mm ARGB fans rotatable 120mm GPU fan supports up to E-ATX motherboards dual 360mm radiators tempered glass side panel and USB 3.2 Gen 2 Type-C

6199 LE
Availability: In Stock
shipped by (sigma)
Point: 100

Model : HAF 500

Seller : sigma

Viewed : 7213 items

Cooler Master HAF 500 Mid-Tower PC Case - Key Specifications

  • Fans: 2 x 200mm ARGB front fans, 1 x 120mm rear ARGB fan, 1 x 120mm top GPU fan (rotatable)

  • Radiator Support: Dual 360mm radiators (front & top)

  • Motherboard Support: ITX, Micro ATX, ATX, SSI CEB, E-ATX (up to 12" x 14.1")

  • GPU Clearance: Up to 410mm

  • CPU Cooler Clearance: Up to 167mm

  • PSU Clearance: Up to 180mm

  • Drive Bays: 2 x 2.5"/3.5" combo bays, 2 x 2.5" bays

  • I/O Ports: 2 x USB 3.2 Gen 1, 1 x USB 3.2 Gen 2 Type-C, 1 x Audio Jack, 1 x Reset/ARGB button

  • Material: Steel, Mesh, Plastic with Tempered Glass side panel

  • Dimensions: 516 x 224 x 510 mm

  • Features: Tool-less side panels, removable top panel, ARGB lighting hub, dust filters (top & bottom), high airflow design




Cooler Master HAF 500 PC Case Mid-Tower

  • 2 x 200mm ARGB Fans

  • Rotatable 120mm GPU Fan

  • Color: Black

Description:
Cooler Master’s classic HAF series is making a return with HAF 500. Built for high airflow and peak performance, the HAF 500 boasts iconic 200mm large intake ARGB fans, ensuring unparalleled intake and cooling efficiency. The chassis features a dedicated GPU fan, adjustable to various GPU lengths. Ample clearance for dual 360mm radiators on the top and front panel accommodates the most advanced water cooling setups.

Tool-less side panels and a removable top panel facilitate simplified, hassle-free component installation without the need to struggle with small spaces. Large filtered intakes promote high airflow, keeping internal components running at optimal temperature.

Iconic 200mm ARGB fans embedded in the core of the HAF Series in design and function move high volumes of air quietly and effectively due to their large size. Utilizing the included hub, ARGB lighting can be customized to create a comprehensive theme to match your build.

A 120mm fan positioned on top of the HDD cage provides dedicated GPU cooling to ensure maximum performance. The fan bracket can be rotated to accommodate various GPU sizes and configurations.

The tempered glass side panel is secured with pins for easy removal, facilitating quick access to the internals without the use of tools. An optional screw can be installed to further secure the tempered glass side panel.

USB 3.2 GEN 2 TYPE C SUPPORT
USB 3.2 Gen 2 Type C ports built into the I/O panel allow multi-purpose, streamlined data transmission.

REMOVABLE TOP PANEL
The top panel is entirely removable for improved access to the components during assembly. Ease of use also facilitates the mounting of cooling solutions such as fans and radiators.

Support for up to eight 120mm fans and dual 360mm radiators on the top and front panel ensure high compatibility for liquid-cooled systems.

Got any unanswered questions or future product requests? Or maybe you just want the latest scoop on upcoming product launches and giveaways? Join our community on Reddit and Discord to talk directly to the designers of the products!


Materials:

  • Outlook: Steel, Mesh, Plastic

  • Side Panel: Tempered Glass, Steel

Dimensions (L x W x H):
516 x 224 x 510mm (including protrusions)

Motherboard Support:
ITX, Micro ATX, ATX, SSI CEB, E-ATX*
(*up to 12" x 14.1", may impact cable management and case features, remove cable cover and GPU fan bracket features)

Expansion Slots: 7
5.25" Drive Bays: N/A
2.5" / 3.5" Drive Bays (Combo): 2
2.5" Drive Bays: 2

I/O Panel:

  • 2x USB 3.2 Gen 1 (formerly USB 3.0)

  • 1x USB 3.2 Gen 2 Type-C

  • 1x Single Audio Jack

  • 1x Reset/ARGB Button

ARGB Controller: ARGB Hub

Pre-installed Fans:

  • Front: 2x 200mm ARGB Fans

  • Rear: 1x 120mm SickleFlow PWM ARGB

  • Top on HDD cage: 1x 120mm SickleFlow PWM (GPU Fan)

Fan Support:

  • Top: 3x 120mm, 2x 140mm, 2x 200mm

  • Front: 3x 120mm, 2x 140mm, 2x 200mm (*200mm Mounting Hole Spacing 154 x 154 with up to 30mm thickness)

  • Rear: 1x 120mm

  • Top on HDD cage: 1x 120mm

Radiator Support:

  • Top: 120mm, 140mm, 240mm, 280mm, 360mm

  • Front: 120mm, 140mm, 200mm, 240mm, 280mm, 360mm

  • Rear: 120mm

Clearance:

  • CPU Cooler: 167mm / 6.5"

  • PSU: 180mm / 7.1"

  • GPU: 410mm / 16.1"

Cable Routing: Behind Motherboard Tray 30mm
Dust Filters: Top, Bottom
Power Supply Support: Bottom Mount, ATX


CategoryDesktop
SubcategoryComputer Case
BrandCOOLER MASTER
ModelHAF 500
