AMD Ryzen 9 9950X 16 cores 32 threads up to 5.7 GHz boost clock 64 MB L3 cache and supports DDR5 memory PCIe 5.0 and overclocking with a 170W TDP

reviews | Write a review

29999 LE

Availability: In Stock

shipped by (sigma)

Point: 60

Brand : AMD

Model : 9950X

Seller : sigma

Viewed : 5702 items

AMD Ryzen™ 9 9950X - Key Specifications

Cores/Threads: 16 Cores / 32 Threads
Base Clock: 4.3 GHz
Max Boost Clock: Up to 5.7 GHz
Cache: 80 MB Total (L2 + L3)
Architecture: Zen 5 (4nm FinFET)
TDP: 170W
Socket: AM5
Integrated Graphics: AMD Radeon™ (2 Cores, 2200 MHz)
Memory Support: DDR5 up to 192 GB (Dual Channel)
PCIe Version: PCIe® 5.0 (28 Lanes)
Overclocking: Yes (Unlocked with AMD EXPO™ & Precision Boost Overdrive)
Cooler: Not Included (Liquid Cooling Recommended)

Seller note

005051000000057

Fast delivery
2-5 Days
Online Support
Chat and Phone
order protection
secured information
promotion gift
special offers!
money back
return over 14 days

AMD Ryzen™ 9 9950X - Specifications

General Information:

Name: AMD Ryzen™ 9 9950X
Family: Ryzen
Series: Ryzen 9000 Series
Codename: Granite Ridge (AM5)
Architecture: Zen 5
Market Segment: Enthusiast Desktop
Form Factor: Desktop (Boxed Processor)
Launch Date: August 15, 2024
Unlocked for Overclocking: Yes

CPU Specifications:

Cores: 16
Threads: 32 (Simultaneous Multithreading)
Base Clock: 4.3 GHz
Max Boost Clock: Up to 5.7 GHz
L1 Cache: 1.28 MB
L2 Cache: 16 MB
L3 Cache: 64 MB
TDP (Default): 170W
Max Operating Temperature (Tjmax): 95°C

Processor Technology:

CPU Cores: TSMC 4nm FinFET
I/O Die: TSMC 6nm FinFET
Package Die Count: 3

Supported Features:

Overclocking Support: Yes (AMD EXPO™, Precision Boost Overdrive, Curve Optimizer)
AMD Ryzen™ Master Support: Yes
CPU Boost Technology: Precision Boost 2
Instruction Set: x86-64
Supported Extensions: AES, AMD-V, AVX, AVX2, AVX-512, FMA3, SSE4.1/4.2, SHA, SSSE3

Memory Support:

Type: DDR5 (UDIMM)
Channels: Dual (2)
Max Capacity: 192 GB
Max Speed:
- 2x1R: DDR5-5600
- 2x2R: DDR5-5600
- 4x1R: DDR5-3600
- 4x2R: DDR5-3600
ECC Support: Yes (Motherboard dependent)

Connectivity:

PCI Express® Version: PCIe® 5.0
PCIe Lanes: 28 (24 usable)
USB Ports:
- 4 × USB 3.2 Gen 2 (10 Gbps)
- 1 × USB 2.0 (480 Mbps)
NVMe Support: Boot, RAID 0/1/5/10

Integrated Graphics:

Model: AMD Radeon™ Graphics
Cores: 2
Frequency: 2200 MHz
USB Type-C® DisplayPort™ Alternate Mode: Supported

Socket & Chipset Compatibility:

CPU Socket: AM5
Chipsets Supported: A620, B650, B650E, X670, X670E, X870, X870E, B840, B850

Thermal Solution:

Included Cooler: Not Included
Recommended Cooler: Liquid Cooler for Optimal Performance

Operating System Support:

Windows 11 (64-bit)
Windows 10 (64-bit)
RHEL (x86 64-bit)
Ubuntu (x86 64-bit)

Category	Desktop
Subcategory	Processors
Brand	AMD
Model	9950X
