HAVN-HS 420 White CASE | AIR Cooling Up to 185mm | VGA Support Up to 480mm | Type-C Ready | GPU Holder | 20000 EGP

HAVN-HS 420 White CASE AIR Cooling Up to 185mm VGA Support Up to 480mm Type-C Ready GPU Holder

20000 LE
shipped by (sigma)
Point: 10

Brand : HAVN brand

Model : HS 420

Seller : sigma

Viewed : 77 items

HS 420 – Engineered for Performance and Elegance

The HS 420 is a remarkable blend of functional beauty and user-focused innovation. Developed through dozens of prototypes, multiple redesigns, and thousands of hours of intensive testing by HAVN and Pro Gamers Group engineers, this Hybrid Structure case is crafted to deliver exceptional central GPU airflow within a dual-chamber layout — all while preserving the compact footprint of a traditional mid-tower.

Built to support the most powerful fans and radiators available, the HS 420 is thermally optimized to meet the highest performance demands.


Key Features

  • UniSheet Panoramic Glass Panel
    Heat-formed for both front and side, engineered to be flatter with a smaller curvature radius, reducing visual distortion and enhancing clarity.

  • Superior Thermal Design
    Features custom ventilation panels, optimized for 140mm fans, with a total of 11 fan mounting positions, and support for radiators up to 420mm on the top, side, and bottom.

  • SimpliCable Routing System
    An intuitive cable management design with an integrated fan hub that keeps your setup clean, organized, and airflow-efficient.





HS 420 Case – Specifications

Form Factor

  • Mid Tower

Material

  • SGCC sheet metal

  • Tempered glass

  • ABS, Nylon, Silicon

  • Zinc alloy

  • NdFeB magnets

Dimensions (L × W × H)

  • 541 × 259.5 × 547 mm


Front I/O Ports

  • USB 3.2 Gen 2 Type-C ×1

  • USB 3.2 Gen 1 Type-A ×2

  • Audio Jack ×1

  • Power & Reset Button ×1


Motherboard Compatibility

  • E-ATX (Max Width: 277 mm)

  • ATX

  • Micro-ATX

  • Mini-ITX


Expansion Slots

  • 6


Fan Support (Up to 11 Fans)

  • Top: 3 × 120 mm / 3 × 140 mm

  • Right: 3 × 120 mm / 3 × 140 mm

  • Bottom: 3 × 120 mm / 3 × 140 mm

  • Rear: 2 × 120 mm / 2 × 140 mm (Thickness up to 30 mm)


Fan PWM Repeater

  • Channels: 12 total

  • Locations:

    • Cable Management Tray ×1

    • PSU Shroud ×1


CPU Cooler Clearance

  • Height: Up to 185 mm

  • Depends on GPU width (CPU center to GPU PCIe edge approx. 199 mm – varies by motherboard)

  • Liquid cooling recommended


Liquid Cooling Support

  • Top: 280 / 360 / 420 mm (Max thickness: 65 mm, non-overlapping with RAM)

  • Right: 280 / 360 / 420 mm (Max thickness: 60 mm with GPU > 317 mm, 80 mm with top AIO)

  • Bottom: 280 / 360 / 420 mm (Max thickness: 120 mm)


Graphics Card Clearance

  • Length: Up to 480 mm

  • Width: Up to 195 mm (Depends on CPU cooler size)

  • Liquid cooling recommended


GPU Support

  • 2 to 5 slots


RAM Clearance

  • If radiator + fan thickness > 65 mm:

    • 420 mm radiator: 32 mm clearance

    • 360 mm radiator: 43 mm clearance


Power Supply Support

  • Form Factor: ATX

  • Length: Up to 220 mm (Clearance up to 290 mm)


Storage Support

  • Right Fan Mount:

    • 4 × 3.5"

    • 8 × 2.5"

  • Cable Management Tray:

    • 1 × 3.5"

    • 2 × 2.5"

  • Total Bays Included: 4


Internal Display Support

  • VESA Mounting: 75 × 75 mm / 100 × 100 mm

  • Display Size: Up to 14 inches

  • Location: Front Right Pillar


Dust Filters

  • Bottom: 1 × Removable

  • Top: 1 × Built-in

  • Right: 1 × Built-in

  • Rear Bottom: 1 × Removable




CategoryDesktop
SubcategoryComputer Case
BrandHAVN
ModelHS 420
