Xigmatek Pano M Nano 3GF M-ATX Case 330mm GPU 158mm CPU Cooler 165mm PSU 240mm Radiator Top MB Up to 7 Fans 3 Drive Bays USB 3.0 x1 Curved Tempered Glass Dust Filters Steel Build.

reviews | Write a review

1650 LE

Availability: In Stock

shipped by (sigma)

Point: 10

Brand : XIGMATEK

Model : Pano M Nano

Seller : sigma

Viewed : 1007 items

Xigmatek Pano M Nano 3GF – Key Specs

Micro-ATX / Mini-ITX support

GPU clearance: up to 330mm

CPU cooler clearance: up to 158mm

PSU length: up to 165mm

Radiator support: 240mm (Top / MB Panel)

Fan support: up to 7 fans

Drive bays: 1x 3.5", 2x 2.5"

I/O ports: USB 3.0 x1, USB 2.0 x2, HD Audio

Curved tempered glass panel

Top & bottom dust filters

Steel construction

Seller note

003190000000094

Fast delivery
2-5 Days
Online Support
Chat and Phone
order protection
secured information
promotion gift
special offers!
money back
return over 14 days

Xigmatek Pano M Nano 3GF – Compact M-ATX Case

Chassis Specifications:

Motherboard Support: Micro-ATX, Mini-ITX
Dimensions: 352 x 270 x 375 mm (L x W x H)
Material: Steel
Expansion Slots: 4 Standard Slots
Tempered Glass: Curved Tempered Glass Side Panel
Dust Filters: Top and Bottom

Cooling Support:

Maximum Fan Capacity: 7 Fans
Pre-installed Fans:
- Rear: 1x 120mm (Traditional Blade)
- Motherboard Panel: 2x 120mm (Reverse Blade)
Fan Mounting Locations:
- Top: 2x 120mm
- MB Panel: 2x 120mm
- Bottom: 2x 120mm
- Rear: 1x 120mm
Radiator Support:
- Top: Up to 240mm
- MB Panel: Up to 240mm

Clearances:

CPU Cooler Clearance: Up to 158mm
GPU Length Limitation: Up to 330mm
Power Supply Length: Up to 165mm

Drive Bays:

HDD Bracket: 1x 3.5″, 1x 2.5″
Bottom Panel: 1x 2.5″

Power Supply:

Type: Standard PS2 ATX PSU

Top I/O Ports:

Power Button
Reset Button
HD Audio Jack
USB 3.0 x1
USB 2.0 x2

Features:

Superior airflow and ventilation design
Dual-direction fan blade support (traditional and reverse)
Compact size with high hardware compatibility

Category	Desktop
Subcategory	Computer Case
Brand	XIGMATEK
Model	Pano M Nano

Xigmatek Pano M Nano 3GF M-ATX Case 330mm GPU 158mm CPU Cooler 165mm PSU 240mm Radiator Top MB Up to 7 Fans 3 Drive Bays USB 3.0 x1 Curved Tempered Glass Dust Filters Steel Build.
