Xigmatek Aqua M Nano II – M-ATX case, supports 155mm CPU coolers, 290mm GPUs, 240mm radiator, up to 7 fans, ATX PSU (150mm), 2 tempered glass panels, USB 3.0. | 1549 EGP

Xigmatek Aqua M Nano II M-ATX case supports 155mm CPU coolers 290mm GPUs 240mm radiator up to 7 fans ATX PSU 150mm 2 tempered glass panels USB 3.0.

1549 LE
Availability: In Stock
shipped by (sigma)
Point: 10

Brand : XIGMATEK brand

Seller : sigma

Viewed : 981 items

Xigmatek Aqua M Nano II – Key Specs

  • Motherboard: Micro-ATX, Mini-ITX

  • CPU Cooler Clearance: 155mm

  • GPU Length: 290mm

  • PSU Length: 150mm (Standard PS2 ATX)

  • Radiator Support: Top 240mm (RAM height ≤ 38mm)

  • Fan Support: Up to 7 fans (120mm x7)

  • Drive Bays: 1 x 3.5"/2.5", 1 x 2.5"

  • Expansion Slots: 4

  • Material: Steel, 2 Tempered Glass Panels

  • Dimensions: 300 x 275 x 312 mm

  • I/O Ports: USB 3.0 x1, USB 2.0 x2, HD Audio, Power, Reset

Xigmatek Aqua M Nano II – Key Specifications

  • Motherboard Support: Micro-ATX, Mini-ITX

  • Dimensions: 300 x 275 x 312 mm (L x W x H)

  • CPU Cooler Clearance: Up to 155mm

  • GPU Length Limitation: Up to 290mm

  • Power Supply Support: Standard PS2 ATX, up to 150mm

  • Drive Bays:

    • HDD/SSD Combo Bracket: 1 x 3.5" HDD or 2.5" SSD

    • Bottom Panel: 1 x 2.5" SSD

  • Expansion Slots: 4

  • Radiator Support:

    • Top: Up to 240mm (with RAM height limit of 38mm)

  • Fan Support:

    • Motherboard Side: 120mm x2

    • Top: 120mm x2

    • Bottom: 120mm x2

    • Rear: 120mm x1

  • Material: Steel

  • Panels: Dual tempered glass

  • Airflow Design: Optimized for superior ventilation

  • Front I/O Ports:

    • USB 3.0 x1

    • USB 2.0 x2

    • HD Audio

    • Power Button

    • Reset Button

CategoryDesktop
SubcategoryComputer Case
BrandXIGMATEK
ModelAqua M Nano II
